DZC2 series Dual-Chamber Oil Quenching Gas-Cooled Vacuum Furnace
DZC series dual-chamber oil quenching gas-cooled vacuum furnace with the possibility of both oil quenching and gas cooling, it is mainly used for vacuum heating treatment of alloy steel, magnetic materials, titanium and so on, and it can also be used for vacuum brazing and vacuum sintering of other materials.
Structure of furnace — horizontal, dual-chamber, furnace is composed of furnace body, hermetically sealed lid, the heating chamber, cooling chamber, inserted middle vacuum insulated door, material basket transport mechanism and so on.
General technical indicators and size of common types of furnaces (about other special indicators, please call us)
Ultimate vacuum: 4 × 10-1 or 6.7 × 10-3 Pa
The pressure of cooling gas: <2 bar
Temperature uniformity in the furnace: ±5℃
型号 Type | 加热区尺寸 Size of heating zone (mm)
| 装炉量 Mass of Load (kg)
| 最高温度 Maximum temperature (℃)
| 加热功率 Heating power (kW)
|
DZC2-40 | 450×300×300 | 60 | 1320 | 40 |
DZC2-65 | 600×400×400 | 150 | 1320 | 65 |
DZC2-85 | 750×500×500 | 300 | 1320 | 85 |
DZC2-120 | 900×600×600 | 500 | 1320 | 120 |
DZC2-260 | 1200×800×800 | 1000 | 1320 | 260 |
