DZQ series Gas-Quenching Vacuum Furnace
DZQ series Gas-Quenching Vacuum Furnace is mainly used for rapid cooling of various alloy steel in particular gas, vacuum annealing of high-temperature alloys, magnetic materials, titanium and so on, and it can also be used for solution treatment of stainless steel and titanium alloys, and for vacuum brazing and vacuum sintering of other materials.
Device host structure — horizontal single-chamber, furnace is composed of the furnace body, vacuum systems, water cooling system, air cooling system, pneumatic system, electronic control system, truck outside the furnace.
General technical indicators and size of common types of furnaces (about other special indicators, please call us)
Ultimate vacuum: 4 × 10-1 or 6.7 × 10-3 Pa
The pressure of cooling gas: 6bar or 10bar
Temperature uniformity in the furnace: ±5℃
型号 Type
| 加热区尺寸 Size of heating zone(mm)
| 装炉量 Mass of load (kg) Масса | 最高温度Maximum temperature (℃)
| 加热功率 Heating power (kw)
|
DZQ-50 | 450×300×300 | 100 | 1320 | 50 |
DZQ-80 | 600×400×400 | 200 | 1320 | 80 |
DZQ-150 | 900×600×600 | 500 | 1320 | 150 |
DZQ-200 | 1200×800×800 | 1000 | 1320 | 200 |
DZQ-300 | 1300×900×900 | 1200 | 1320 | 300 |
